HERMS Brew Table
Accessory · Bräu Supply

HERMS Brew Table

✓
Designed and assembled in Vancouver, BC.

A stainless brew table for a three-vessel HERMS. Your hot liquor tank, mash tun and boil kettle sit in a row at working height, with both pumps and the chiller mounted underneath, so recirculation and transfer runs stay short and repeatable.

  • Raised edge around the top keeps spills on the table.
  • Recessed drain with a 5/8" hose barb. Run a hose to your floor drain and hose the top down after brew day.
  • Reinforced top and frame to carry three full vessels.
  • Pump shelf with two pump mounts for the HERMS recirculation and transfer pumps, plus mounting points for the counterflow chiller.
  • Second shelf for hoses and tools.
  • Adjustable feet to level it on an uneven floor.
  • 304 stainless top, shelf and pump shelf (1.0 mm), stainless frame.
Size Footprint Top height Shipping weight
10G / 20G HERMS 78.7" × 23.6" (200 × 60 cm) 22" (56 cm) 150 lb
30G / 50G HERMS 96" × 23.6" (244 × 60 cm) 22" (56 cm) 180 lb

Ships with a HERMS system. The table goes by freight, so we ship it together with your system. Pick “+ HERMS Brew Table” when you configure your HERMS and we match the size to your vessels. Need one shipped on its own? Ask us for a freight quote.

Step 1 — Choose your size 10G / 20G
$1,307.00Ships from Vancouver, BC · rates calculated at checkout
Ships with a brewing system The table goes by freight, so we ship it together with your HERMS system. Pick “+ HERMS Brew Table” when you configure your system and we match the size to your vessels.
Add it with a HERMS system

Need one shipped on its own? Ask us for a freight quote →

→
Ready to ship · most orders out in under a week
2y
2-year warranty · lifetime parts · every part replaceable
✉
Talk to a brewer, not a sales rep · email or call — real humans
