Add Chiller Watch, or skip it.
Chiller Watch is the MCED digital controller — set point, differential, low-pressure cutout, alarm relay, cloud-connected for remote monitoring. On the High Capacity tier it's standard; on Production tier it's an optional add. Many production buyers already have brewery SCADA / BMS and don't need a second controller. Skip it if you've got that infrastructure; add it if you want MCED's cloud monitoring.
Single, dual, or triple pump?
Production-tier chillers can carry up to 3 independent fermenter zones. Pick by how many simultaneous fermenter loops you need to feed at different flow rates.
Pick a connection kit, or BYO plumbing.
The chiller ships ready to plumb into anything via NPT — pick a connection kit if you want the matched controller + solenoid + thermowell + glycol line set for our Unitank or DrainPro Fermenter. Glycol fluid is NOT included; use food-safe propylene glycol only (never ethylene), mixed to ~30% propylene of total system volume.
What the Production Series will cool.
Both Production models share the 220V plug-in form factor and integrated 17-gal bath. Step up to BFT-67 reservoir for 10+ fermenter halls. Step further to the Industrial Series (BEF-300/-500) for 20+ BBL production cellars.
BEF-100 · 8,179 BTU
4–6 1 BBL fermentersSized for a 5 BBL hall with 4–6 1 BBL fermenters under typical brewery duty. 220V plug-in with NEMA 6-20P — no electrician required if your cellar has 220V available. Single, dual, or triple pump for independent fermenter zones.
Connection kit · $570BEF-150 · 12,900 BTU
6–10 1 BBL fermentersFor 10 BBL halls running 6–10 fermenters or smaller halls running back-to-back lager crashes. Same 220V plug as BEF-100; bigger compressor + bigger pump deck handle the higher BTU load.
Connection kit · $570+ BFT-67 reservoir
Up to 10 fermentersBoth Production models upperdeck onto the BFT-67 modular reservoir (67 gal bath, up to 10 pumps, 2 chiller decks for redundancy). Standard pairing for 10 BBL halls running 3+ fermenters in parallel.
See BFT-67 →In the crate.
220V plug-in install. Both Production models ship with a NEMA 6-20P plug for 220V single-phase outlets. No electrician required IF your cellar already has 220V available; otherwise a licensed electrician needs to run a 220V/20A circuit (1–2 hours of work).
-
✓
MCED Production chiller cabinet Commercial-grade hermetic compressor, copper evaporator coil, insulated 17 gal water bath, multi-pump deck. Cabinet ~30" × 25" × 32" — castor-mounted floor unit.
-
✓
Commercial pump deck — 1, 2, or 3 pumps 100 GPH per pump (vs. 50 GPH on High Capacity tier). Configurable in Step 3 — single, dual, or triple. NPT supply + return on the back panel for each pump zone.
-
✓
Water bath — 17 US gal Insulated reservoir for thermal mass. Upperdecks onto BFT-67 (67 gal) when you need centralized multi-fermenter cooling.
-
✓
Power cord · 220V · NEMA 6-20P 220V single-phase plug. Standard 6-20 outlet — no hardwiring required IF your cellar already has 220V. Otherwise a licensed electrician runs a 220V/20A circuit.
-
✓
Low-pressure safety cutout Hardware safety — protects the compressor if refrigerant pressure drops below safe operating range. Included regardless of whether you add Chiller Watch.
-
✓
Install & user manual Plumbing diagram, control wiring guide, glycol fill instructions, maintenance schedule.
*Glycol fluid not included. Use food-safe propylene glycol only (never ethylene). Mix to ~30% propylene of total fluid volume (17 gal bath + jacket/coil + lines).
Refrigeration loop. Commercial-duty.
The Production Series is sized for breweries running multiple fermenters in parallel under commercial duty — bigger compressor, multi-pump deck, 220V power. Optional Chiller Watch for cloud monitoring if you don't already have brewery automation.
01 · Compressor — commercial hermetic
Sized for sustained pull-down across 4–10 fermenters in a commercial brewery. 2× the BTU output of the High Capacity tier; 60% duty cycle under typical brewery load.
02 · Evaporator — copper tube + 17 gal bath
Same form factor as High Capacity but with a larger refrigerant charge. Upperdeck to BFT-67 (67 gal) for centralized cooling across a fermentation hall.
03 · Pump deck — 1, 2, or 3 commercial pumps
100 GPH per pump (vs. 50 on High Capacity). Independent flow rates per zone — feed primary, crash, and secondary fermenters at their own ideal pressures.
04 · Chiller Watch — optional cloud monitoring
Optional add-on. Production buyers often already have brewery SCADA / BMS / control panels — paying for Chiller Watch they don't need pads the price. Add it ($695 TBC) if you want MCED cloud monitoring; skip if you have existing automation.
Specs by model.
8,179 BTU/hr · evap 25°F, ambient 90°F
1 HP hermetic · commercial-duty
R513a · low-GWP
100 GPH per pump (1, 2, or 3 pumps available)
17 US gal · insulated · BFT-67 upperdeck-compatible
220V · 60Hz · single phase · NEMA 6-20P plug · 15A running · 20A circuit
Basic on/off thermostat standard · Chiller Watch optional (+$695 TBC)
~30" W × 25" D × 32" H · ~180 lb dry (1 pump) TBC
4–6× 1 BBL fermenters · 5 BBL hall typical install
From $4,299 USD · current sale
12,900 BTU/hr · evap 25°F, ambient 90°F
1.5 HP hermetic · commercial-duty
R513a · low-GWP
100 GPH per pump (1, 2, or 3 pumps available)
17 US gal · insulated · BFT-67 upperdeck-compatible
220V · 60Hz · single phase · NEMA 6-20P plug · 18A running · 25A circuit
Basic on/off thermostat standard · Chiller Watch optional (+$695 TBC)
~30" W × 25" D × 36" H · ~210 lb dry (1 pump) TBC
6–10× 1 BBL fermenters · 10 BBL hall typical install
From $4,799 USD · current sale
Other chillers in the MCED lineup.
High Capacity (BEF-04/-05/-075) is the 120V tier with Chiller Watch standard. Industrial (BEF-300/-500) is quote-based hardwired for 20+ BBL halls. BFT-67 reservoir for centralized multi-fermenter setups.
About the Production Series.
BEF-100 or BEF-150?+
By hall size. BEF-100: 5 BBL hall, 4–6 1 BBL fermenters under typical brewery duty. BEF-150: 10 BBL hall, 6–10 fermenters, or smaller halls running back-to-back lager crashes. Both 220V plug-in; the difference is compressor size and BTU output.
Why is Chiller Watch optional here but standard on High Capacity?+
Production-tier buyers often already have brewery SCADA, BMS, or a dedicated control panel reading every cellar variable including chiller status. Forcing Chiller Watch into the base price would mean charging for a controller many buyers won't use. Add it ($695 TBC) if you want MCED's cloud monitoring; skip if you have existing automation.
Do I need an electrician for 220V?+
Not necessarily. The Production chillers ship with a NEMA 6-20P plug — a standard 220V single-phase plug. If your cellar already has a 220V/20A outlet (some breweries do; many electric brewhouses have one), you plug it in and go. If not, a licensed electrician needs to run a 220V/20A circuit — typically 1–2 hours of work and $300–500 in materials.
Should I get the dual or triple pump version?+
Pick by how many fermenter zones you want feeding at independent flow rates. Single pump: 1–3 fermenters sharing flow (fine for matched conditions). Dual pump: 2 independent zones (most common). Triple pump: 3 independent zones (for commercial cellars running primary + crash + secondary at the same time at different pressures).
Can I add a BFT-67 reservoir later?+
Yes — both Production models upperdeck onto the BFT-67 (67 gal bath, up to 10 pumps, 2 chiller decks for redundancy). When you outgrow the integrated 17 gal bath, the BFT-67 is the upgrade path. Bolt-on, no chiller replacement needed. See BFT-67 →
Why isn't glycol included?+
Pre-mixed propylene glycol is heavy and hazmat-classed — including it would substantially raise the freight cost. Any HVAC supplier carries food-safe propylene glycol at a lower per-gallon price than we could ship it for. Buy food-safe propylene glycol (never ethylene — that's automotive antifreeze and toxic). Mix to ~30% propylene of the total fluid volume — that's the 17 gal bath plus everything held in your fermenter jackets and the connecting lines.
Shipping & freight?+
7–14 days from order. Ships LTL palletized with a delivery appointment (commercial dock or curbside lift-gate). Free continental US shipping; duties, tariffs & brokerage prepaid.
What's the warranty?+
1-year warranty on the refrigeration loop. Warranty service is direct through MCED Systems — they manufacture the unit and service it. Production-tier installations get priority parts dispatch from MCED.
220V plug-in.
5–10 BBL hall.
MCED Production Series — commercial chillers that don't need a hardwired install. Pair with BFT-67 reservoir for multi-fermenter cooling. Manufactured in Canada by MCED. 1-year warranty.
